The electron microscopy lab at IKOM is a life science electron microscopy lab, with experienced personnel who can assist research with various forms of sample preparation and staining of biological material such as tissues, cells, bacteria and viruses.

Equipment such as ultramicrotomes and electron microscopes can as well be used for non-biological samples.

We have transmission electron microscopy (TEM), scanning electron microscopy (TEM), and serial block-face scanning electron microscopy (SBF SEM). In addition, we have various equipment intended for sample preparation.

Users should receive training in microscopy (2 days) and microscope their own samples as much as possible. This will free up engineering capacity so that more projects can be carried out/helped with sample preparation. Sample preparation must be adapted for each problem and type of sample.

For new projects, an assessment will be made of capacity, method, possibility for method testing, etc. Some project requests may have to be rejected based on insufficient capacity for method testing or project implementation.

All projects, both internal and external, that want to use the EM lab must send a request to IKOM research support by email: forskningsstotte@ikom.ntnu.no. Users must inform about their planned activity and timeframe. Users are encouraged to notify early and think long-term, as EM work takes some time. You will then be contacted by email to investigate further the needs of the projects and to clarify capacity at the EM lab.

For internal (IKOM) users, expenses are covered through rental “leiestedsbetaling”. For external users, a price will be agreed based on the needs and duration of the projects.

Please fill out this Quotation-form for using EMLab.

See more about all our equipment below.

Back to IKOM research page


Transmission Electron Microscope Tecnai 12

Transmission Electron Microscope Tecnai 12

Photo of Transmission Electron Microscope Tecnai 12
Instrument specification: Transmission Electron Microscope Tecnai 12 (pdf)

Ultramicrotomes

Ultramicrotomes

Photo of Ultramicrotomes for room temperature sectioning
Instrument specification: Ultramicrotomes (pdf)

PELCO BioWave Pro+

PELCO BioWave Pro+

Photo of PELCO BioWave Pro+
Instrument specification: PELCO BioWave Pro+ (pdf)

Transmission Electron Microscope JEM-1011

Transmission Electron Microscope JEM-1011

Photo of Transmission Electron Microscope JEM-1011
Instrument specification: Transmission Electron Microscope JEM-1011 (pdf)

Vibratome Leica EM VT1000S

Vibratome Leica EM VT1000S

Photo of Vibratome Leica EM VT1000S
Instrument specification: Vibratome Leica EM VT1000S (pdf)

Coater Leica EM ACE600 – Sputter, carbon and glow discharge coating system

Coater Leica EM ACE600 – Sputter, carbon and glow discharge coating system

Photo of
Instrument specification: Coater Leica EM ACE600 – Sputter, carbon and glow discharge coating system (pdf)

Teneo VolumeScope with SEM


Teneo VolumeScope with SEM

Photo of Teneo VolumeScope with SEM
Instrument specification: Teneo VolumeScope with SEM (pdf)

Knife maker Leica EM KMR3

Knife maker Leica EM KMR3

Photo of Knife maker Leica EM KMR3
Instrument specification: Knife maker Leica EM KMR3 (pdf)

Critical point dryer Leica EM CPD300

Critical point dryer Leica EM CPD300

Photo of Critical point dryer Leica EM CPD300
Instrument specification: Critical point dryer Leica EM CPD300 (pdf)
